On August 8, the HT10B mini excavator was loaded in the Industrial Park and will be sent to Russia. At present, series products have obtained EU CE certification, ISO quality system certification, TVU certification, etc.
The crawler excavator is a compact excavator ,which matched KUBOTA national III engine , the boom ofexcavator can swing to left or right , suitable for different director digging for your working , fitted international brand main pump and valves and driving motor and slewing motor, hydraulic pilot servo operation system,with steel track, with broken pipeline system , the machine can change track from steel to rubber. Cantelescoping the track frame. Compact, light and small turning radius, are its unique structural features; which makes it plays a biggest role in limited working sites.
Machine Size |
|
Overall dimension (L*W*H) |
3555mm*1300mm*2290mm |
Axle base(Track length on ground) |
1230mm |
Track gauge |
760mm |
Min.Ground clearance |
150mm |
Swing radius at tail |
650mm |
Track System |
|
Maximum Travel speed |
4km/h |
Width of track shoe |
230mm |
Number of track shoe per side |
38pcs |
Number of upper roller per side |
1 |
Number of bottom roller per side |
3 |
Performance Parameter |
|
Standard bucket capacity |
0.07m³ |
Swing speed |
9rpm |
Max. Grade ability |
35° |
Max. Bucket digging force |
18KN |
Max. Arm digging force |
11KN |
Hydraulic system pressure |
21.5Mpa |
Machine weight |
2000kg |
Engine |
|
Emission Standard |
Euro 5/EPA |
Engine Brand |
Kubota |
Model |
D1105 |
Power/Rotation speed |
14.1kw(20HP) 2000rpm |
Number of cylinder |
3 |
Working Range |
|
Max. Digging height |
3700mm |
Max. Dumping height |
2440mm |
Max. Digging depth |
2400mm |
Max. Vertical digging depth |
2025mm |
Max. Digging radius |
4040mm |
Min .swing radius |
1610mm |
Max. Lifting height of blade |
240mm |
Max. Cutting depth of blade |
270mm |
Boom swing angle(Left) |
75° |
Boom swing angle(Right) |
45° |
